Corslet Live Optical Fiber Identifier With Visual fault Locator VFL Digital Multimeter (Blue 2000 Counts)

Price: Not Available

Currently Unavailable

Highlights

Material: Plastic
Display Type: LCD
Technology Used: Optical Fiber Identifier & Visual Fault Locator Fiber with Red Light Source Is a Kind of Optical Fiber Maintenance Necessary Tools for Optical Fiber Identification Work, as Well the Red Light Source Can Be Used to Test the Light Transmission of the Optical Fiber Line Any Position of the Mode Fiber Is Detected. This Optical Fiber Detector Is Equipped with VFL Function and a 2.5mm Diameter Universal Interface. PRODUCT FEATURE -: Wavelength Recognition Range: 800nm to 1700nm. Signal Identification Type: CW, 270 Hz ± 5%, 1 KHz ± 5%, 2 KHz ± 5%. Detector Type: φ1mm InGaAs. 2 Pcs Adapter Fiber Type: General φ0.25 (Bare Fiber), φ0.9, Φ2.0, φ3.0 Optical Fiber Sheath Signal Direction: LED Indicator Light to Indicate Left and Right Directions Optical Power Reading Range: -40 DBm To 10 DBm. Signal Frequency Range: 270Hz, 1kHz, 2kHz Battery: Operating Temperature Range: -10℃ To 60℃. Storage Temperature Range: -25℃ To 70℃. VFL Function Power Range: 10mW. Test Distance: 8-10km . Wavelength Range: 650nm.

Specifications

General

Brand	Corslet
Model Number	Live Optical Fiber Identifier With Visual fault Locator VFL
Type	Digital
Display Type	LCD
Color	Blue
Material	Plastic
Primary Functions	Identifies the Traffic Direction and Frequency Tone (270Hz, 1KHz, 2KHz)
Number of Counts	2000
Model Name	Live Optical Fiber Identifier With Visual fault Locator VFL
Brand Color	Blue & Black
LED Indicators	Yes
Operating Temperature	-10+60°C
Display Size	25x20mm
Data Freeze	No
Autoranging	Yes
Reading Storage	Yes
Backlight	Yes
PC Connectivity	No

Power Features

Battery Type	AA
Number of Batteries	2

Additional Features

Technology Used

Optical Fiber Identifier & Visual Fault Locator Fiber with Red Light Source Is a Kind of Optical Fiber Maintenance Necessary Tools for Optical Fiber Identification Work, as Well the Red Light Source Can Be Used to Test the Light Transmission of the Optical Fiber Line Any Position of the Mode Fiber Is Detected. This Optical Fiber Detector Is Equipped with VFL Function and a 2.5mm Diameter Universal Interface. PRODUCT FEATURE -: Wavelength Recognition Range: 800nm to 1700nm. Signal Identification Type: CW, 270 Hz ± 5%, 1 KHz ± 5%, 2 KHz ± 5%. Detector Type: φ1mm InGaAs. 2 Pcs Adapter Fiber Type: General φ0.25 (Bare Fiber), φ0.9, Φ2.0, φ3.0 Optical Fiber Sheath Signal Direction: LED Indicator Light to Indicate Left and Right Directions Optical Power Reading Range: -40 DBm To 10 DBm. Signal Frequency Range: 270Hz, 1kHz, 2kHz Battery: Operating Temperature Range: -10℃ To 60℃. Storage Temperature Range: -25℃ To 70℃. VFL Function Power Range: 10mW. Test Distance: 8-10km . Wavelength Range: 650nm.

Other Features

[ FIBER IDENTIFER ]- Red Light Source All-In-One; Test Without Changing Fixtures Three Signal Frequencies Can Be Identified;10mw Red Light Source/direction/indicator Power Display/ 270/1k/2khz /Led Lights/10mw VFL., [ ERGONOMIC DESIGN ]- When Holding the Machine Index Finger Press the Back Trigger Switch, Clamp the Fiber Optic Cable to Automatically Start the Test Press Down to Clamp the Fiber Optic Cable., [ HIDDEN RED LIGHT SOURCE/LED LIGHT ]- Stable and Strong Speed of Light Concentration, Effectively Cooperating with Line Detection Flip in the Direction of the Arrow to Open 10mw Red Light Source Led Lights(long Press the VFL Button to Turn on the Led Light)., [ MICROBEND TEST TECHNOLOGY ]- Accurately Identify Fiber Direction When the Optical Fiber Has a Signal, The Left and Right Direction Lights Show the Signal Direction the Left Direction Light Is On, Indicating That the Light Source Is from Right to Left. Universal Fixture Design / Power Display / Direction Recognition.

Dimensions
