    MSI A88X-G45 GAMING FM2+Socket ATX AMD A88X Chipset DDR3 Motherboard

    MSI A88X-G45 GAMING FM2+Socket ATX AMD A88X Chipset DDR3 Motherboard

    Price: Not Available
    Currently Unavailable
    3 Years MSI India Warranty and Free Transit Insurance.Know More
    Highlights
    • AMD A88X
    • Data Rate DDR3
    • Maximum RAM Capacity 64
    • Form Factor: ATX
    Specifications
    In The Box
    Sales Package
    • Motherboard, 2 x SATA3 Cables, I/O Panel Shield
    General
    Brand
    • MSI
    Model ID
    • A88X-G45 GAMING
    Essentials
    Form Factor
    • ATX
    Socket Type
    • FM2+
    Compatible Processors
    • AMD A-Series Processors, AMD Athlon Processors
    Chipset
    • AMD A88X
    Chipset Manufacturer
    • AMD
    Memory
    Number of Memory Slots
    • 4 Slots
    Memory Configuration
    • 64 DDR3 Dual Channel DIMM
    Memory Frequency
    • 1600 MHz, 2400 (OC) MHz, 2133 MHz, 1333 MHz, 1866 MHz
    ECC Support
    • Non-ECC
    Buffered Memory
    • Unbuffered
    Storage
    SATA 6 Gb/s
    • AMD A88X
    RAID Controller
    • AMD A88X
    RAID Configurations
    • 0, 1, 5, 10
    Graphics
    Multi GPU Support
    • Yes, Supports AMD CrossFire Technology, Supports Windows: 7, 8, 8.1
    Audio
    Audio Codec
    • RealtekALC892 Codec
    Audio Channels
    • 7.1
    Audio Features
    • Supports S/PDIF output
    Connectivity
    Ethernet Controller
    • Killer E2205 Gigabit LAN Controller
    Ethernet Features
    • 10/100/1000
    Expansion Slots
    PCI Slots
    • 1
    PCIe x1 Slots, Generation
    • 2, 3
    PCIe x16 Slots, Generation
    • 3, 3
    Internal I/o Headers
    SATA 6 Gb/s Headers
    • 8
    USB 2.0 Headers
    • 3
    ATX Power Connectors
    • 1 (24 Pin ATX Power Connectors), 1 (8 Pin ATX 12V Power Connectors)
    Fan Headers
    • 1 (Processor Fan Headers), 4 (System Fan Headers)
    Front Panel Headers
    • 1
    Other Connectors
    • 1 x OC Genie Mode Switch, 1 x 4-pin CPU Fan Connector, 2 x 4-pin System Fan Connectors, 2 x System Panel Connectors, 2 x 3-pin System Fan Connectors, 1 x Clear CMOS Jumper, 1 x Serial Port Connector, 1 x Slow Mode Booting Switch, 1 x OC Genie Button, 1 x Power Button, 1 x Chassis Intrusion Connector, 1 x Reset Button, 1 x 2-digit Debug Code LEDs
    Back Panel Ports
    USB 2.0 Ports, Controller
    • 2
    USB 3.0 Ports, Controller
    • 6
    HDMI Ports
    • 1
    DVI Ports
    • 1
    VGA/D Sub Ports
    • 1
    Audio I/O Channels
    • 6
    Optical S/PDIF Ports and S/PDIF Out ports
    • 1 (Optical S/PDIF Ports)
    RJ-45 Ethernet Jacks
    • 1
    PS/2
    • 1
    Other Ports
    • 1 x DVI-D Port, 1 x Display Port
    General Features
    Overclocking
    • OC Genie 4: Overclock in 1 Second
    BIOS
    • Click BIOS 4: Easily Fine-tune Your System
    Features
    • CrossFire: Y, DirectX: DX11, VGA Max Share Memory (MB) 1760, 9 Mounting Holes, Dimensions: 305 x 244 mm
    Advanced Features
    • Audio Boost: Reward Your Ears with True Quality, Military Class 4: Top Quality and Stability, Military Class Essentials: Total Protection for Military Class Motherboards, PCI Express Gen 3: World's 1st PCI Express Gen 3 Motherboard Brand, Sound Blaster Cinema: Realistic Surround Sound Experience, Gaming Device Port: Optimized with Triple Gold-plating for High Polling Rate Gaming Devices, Smart Fan Control: Optimize All Fan Speed As You Wish, Command Center: Control & Customize Your PC Settings, Fast Boot: Quickly Boot Up & Enter OS in A Few Seconds
    Warranty
    Domestic Term
    • 3 Years MSI India Warranty and Free Transit Insurance.
    Warranty Summary
    • 3 Years MSI India Warranty and Free Transit Insurance.
    Covered in Warranty
    • Manufacturing Defects
    Not Covered in Warranty
    • Forceful Tampering, Burnt, Mishandling and Physical Damage
    Warranty Service Type
    • Carry In
